4 Axis CNC Machining Centre with Split Structure

The split type polyfoam 3D CNC foam cutting machine is a CNC carving machine designed for foam processors who are subject to transportation, site restrictions or format restrictions, and is mainly used in the aviation industry, woodworking industry, craft gifts, film and television. 3D sculptures such as props, building models, electronics, CAD/CAM industrial molds.
Availability:

4 Axis CNC Foam Cutting Machine Description:

High Z axis, heavy duty structure, spindle rotation 110 degree, can make 2d 3d 4d engraving, arc-surface engraving, cutting, engraving, drilling and milling! very suitable for processing deep wood, foam, plastic, wood mould works, also widely used for woodworking.

Split Type Polyfoam 3D CNC Router

Split Type Polyfoam 4 Axis CNC Router


CNC Foam Cutting Machine Technical Data:

X, Y Axis Working Area

mm

2000*3000/2000*4000

Z Axis Working Height

mm

400-1200 optioned

Positioning Accuracy

mm

0.05

Re-positioning Accuracy

mm

0.02

Body   Structure


Welding Body

X, Y Axis Structure


Linear   Guide Rail, Gear Rack

Z Axis Structure


Linear   Guide Rail, Screw

Max.   Running Speed

mm/min

50000

Max. Working Speed

mm/min

20000

Spindle

kw

9.0kw Air-cooling ATC SpindleOptioned

Spindle RPM

rpm/min

24000

Working Voltage

V/Hz

AC 380V±10%/50-60Hz

Machine Weight

kg

3000/3300


CNC Foam Cutting Machine Configuration:

Spindle

HQD Air-cooling   Spindle

(Italy HSD Spindle   Optioned)

Machine Body

Split-type Welding   Body, Fixed with Screw

Worktable

Iron Cast Worktable   (Vac-sorb Worktable with T-slot Optioned)

Control System

Taiwan LNC SystemTaiwan SYNTEC System Optioned

Stepper Motor

Japan YASKAWALeadshine and Yako Optioned

FrequencyConverter

Taiwan DELTA

Gear Rack

Taiwan HIWIN

Reducer

Japan SHIMPO

Electric Components

France SCHNEIDER

Limited Switch

Japan OMRON

Tool Setting

High-precision Automatic Tool Setting Device (Optioned)

Lubrication System

Automatic Lubrication   Device (Optioned)


Size

1


Features Of CNC Foam Cutting Machine:

Stable Operation

Split Structure Body

Third-generation Gantry Iron Cast Worktable France Schneider
Split Structure Body Third-generation Gantry Iron Cast Worktable France Schneider
High-precision
Taiwan HIWIN Guide Rails Japan YASKAWA Servo Japan SHIMPO Reducer Air-cooling ATC Spindle
Taiwan HIWIN Guide Rails Japan YASKAWA Servo Japan SHIMPO Reducer Air-cooling ATC Spindle
Upgrade
Automatic Tool Sensor Automatic Lubrication Taiwan LNC System Dust Collector
Automatic Tool Sensor Automatic Lubrication Taiwan LNC System
Dust Collector
Options
Taiwan SYNTEC System Worktable Rotary Device Vac-sorb T-slot Worktable Linear Tool Changer
Taiwan SYNTEC System Worktable Rotary Device Vac-sorb T-slot Worktable Linear Tool Changer


4 Axis CNC Machining Centre Application:

The plug-in polyfoam 4 axis CNC foam Cutting machine is easy for transport, provide several configurations to meet different requirement, perfect for several kinds of foam and mould router, the innovation model designed by iGOLDENCNC, combined with a competitive set of configurations.

Hot applications include:

>Carving all kinds of non-metal materials processing such as foam, lost foam, automobile foam mold, yacht mold, large ship wooden mold, cast wooden mold, engineering plastic materials, aviation wooden mold, propeller, train wooden mold, etc.

>Foam processing of automotive stamping molds, casting wood molds, automotive interiors, processing of engineering plastic materials;

>Other industry molds: electrical appliance molds, lighting molds, ceramic sanitary ware, three-dimensional curved surfaces for large musical instruments, instrument molds, home appliance molds, air-conditioning molds, automotive molds, automotive interior molds, etc.
