Portable Edge Bander Edge Banding Machine For Sale

Portable edge bander and equipment with various options and accessories. Anyone who regularly glues edges ensures good results at all times with a portable edge bander. Our edge banding machines are particularly suitable for gluing solid wood edges, veneer edges as well as plastic edges and are optionally available with or without corner rounding function.

Features of portable edge bander:

It can achieve the gluing, end cutting, rough trimming, fine trimming, tracking, scraping and polishing functions automatically.

With high-quality WSN cylinder and EASUN solenoid valve, it applies glue in a stable and uniform way. Profile tracking function rounds the four corners, making them more smooth and safer.

Automatic operation greatly improves edge banding efficiency and saves labor costs.

The guide rails of the edge banding machine should be cleaned every day. I recommend adding the 46th rail oil to the sliding surface, or the oil sealing hole. The edge banding machine oil water separator and oil cup is filled with low viscosity air compressor oil; add two-thirds of the oil cup. For the edge banding machine main drive motor, check the gear oil whether need to add every two months. The gears under the glue box of the edge banding machine should be inspected and cleaned every 40 hours, and filled with high viscosity grease.

The head rail part needs to be blown clean with an air gun every day, and then injected into the sewing machine oil or transformer oil, one or two times a day.

Also, the change of worn machine parts is very important, to keep the machine in normal use and increase the safety during work.

Those edgebander parts are most easily worn, please be noticed:

Polishing Wheels: they are used for edge banding machine polishing and buffing wood panel edge. Normally need to replace every 2 months, if your edgebander working too often.

Edgebander Pressure Roller Wheels: they are edge conveyor wheel with high quality HSK bearing. Normally they can be used for 1-2 years based on the toughness of workpiece and other factors.

Edgebander Track Pads: they are made of high quality nylon and rubber, last for long time working. Around 2 years use life based on using situation.

Side Rollers Beam Wheels: these side rollers support at both ends, which helps in easy movement and feeding of workpiece on the table. Because they only in the function of supporting the workpiece to move, so they have a very long use life.

Product  Details:

Scope of application

This machine is suitable for linear edge banding and edge banding materials of solid wood board, fiberboard, particle board and other plate workpieces.

Available solid wood strips, pvc, melamine, veneer strips, etc.
