Four-Process CNC Cutting Machine Wood 4 Head CNC Router

Generally speaking, the four-process CNC cutting machine refers to a single-station equipment. In addition, some other functions can be added, including a double-station four-process panel furniture cutting machine, automatic loading and unloading, and four-process cutting. machine.

The double-station four-process CNC cutting machine adds a worktable on the basis of the single-station. The double-station CNC cutting machine is a device with two worktables. When the sheet is processed in one of the stations , The other station can simultaneously carry out the work of feeding and unloading. After one station is processed, it can be directly processed in the other station. The two stations work alternately. The machine has high production efficiency and saves time.

5 Essential accessories for your 4 head cnc router maintenance

1. CNC router bits

CNC Routers use a variety of router bits. A wood  CNC router bit is important because it will determine the type of carving that you do, the resolution of the finished piece and how fast your router can move through the material. But with a lot of work or improper operation, the tool is very easy to wear and damage. Therefore, we need prepare some backup cutting tools at hand.

2. CNC collet

Collets are manufactured from softer metal than tool-holders and feature special slots and cutouts allowing them to “collapse” and “spring” to tightly grip the cutting tool. As a result, they will wear out faster than the holders will.

3. CNC tool holder

Toolholder wear can not only reduce accuracy but also quickly wear out cutting tools and risk damage to the machine spindle or the holder itself

4. Automatic tool changer tool forks

CNC tool holder forks wear out over time.  If the HSK/ISO30/BT spindle is not clamping the tool properly, it may be the tool holder fork is worn which causes alignment issues.

5. Vacuum suction pods and cover

The vacuum block pads are very suited for handling of workpieces in wood processing, such as furniture parts, floorboards, MDF, and particle board etc. CNC vacuum suction pods are widely used in the wood industry for vacuum suction clamp during machining, sanding etc with P.T.P. CNC machining center with vacuum pods bars. They are easy to find in Biesse,Homag CNC machine. If they are damaged, it will cause the workpiece to not clamp very tightly, affecting normal production.

Advantages of the cnc router machine for wood handle control system:

save space and do not need to occupy the computer; Disadvantages: it is relatively troublesome to operate, and it is easy to press the wrong function key if the operation is not skilled.

Advantages of computer control system: You can preview the processing effect, and you can see the processing track at any time. If the program is loaded incorrectly, it can be corrected in time; Disadvantage: It takes a computer and increases the production cost.

Therefore, for two different control systems, customers can choose their own control methods according to their own processing characteristics when purchasing cnc machine woodworking equipment. In this way, the processing performance of the woodworking engraving machine can be exerted more reasonably, and the selection of suitable equipment models and configurations can also reduce production costs to a certain extent.
